Chromoly Heim Joint

$52.87

Chromoly Housing, 3 piece high-performance Teflon race

Bearing Race: 3 piece teflon

Ball: heat treated, hard chrome plated bearing steel

Finish: bright polished chrome

Housing: 4130 heat treated chromoly steel

Application: Our Chromoly rod ends are ideal for automotive after market suspensions such as control arms, end links and ball joints.

Ultimate Static Load Rating 3/4 : 25,489 lbs

Ultimate Static Load Rating 5/8 : 19,751 lbs

FK Rod End/ Heim Joint

$47.23

The FK rod end bearings are the premium option for our angle kits that offer supior bearing life, extreme strength and a smooth feel. We offer them in 2 sizes, both left hand (LH) and right hand (RH).

The JMX10 is a PTFE lined 5/8-18 bearing with a yield strength of 17,959 lbs.

The JMX12 is a PTFE lined 3/4-16 bearing with a yield strength of 28,090 lbs.

Tierod Body for Mantis kits

$39.75

Our rigid tie-rod for the FDF Mantis kits.

Quantity- Price is for 1 tie-rod

Material- 7075 Aluminum

Benefits over regular tie-rods

Very stiff design, does not flex like the thin steel tie-rods, this improves handling.
Machined fail point to save your steering rack on impact.
Stronger than steel but super lightweight.

We have 7 lengths that currently go with there corresponding angle kits, please select one of the 7 options for your kit

4.5" long (these have a m14x1.5 RH thread, and a 5/8-18 LH thread)

-Corvette, S197, Genesis

6.5" long (these have a m14x1.5 RH thread, and a 5/8-18 LH thread)

- S550, SN95, 370Z mini

8.5" long (these have a m14x1.5 RH thread, and a 5/8-18 LH thread)

-E36, FRS base,

9.5" long (these have a 5/8-18 RH thread, and a 5/8-18 LH thread)

- 350Z reg

10" long (these have a m14x1.5 RH thread, and a 5/8-18 LH thread)

-E46

11.5" long (these have a 5/8-18 RH thread, and a 5/8-18 LH thread)

-240sx, 350z mega, is300/jzx,

13" long (these have a 5/8-18 RH thread, and a 5/8-18 LH thread)

-E46 full tierod setup, frs power kit,

Rx7 FC Knuckle Assembly Spare Parts

$476.94

Parts list

Prices in CAD currency

#1R	*Rx7 FC Knuckle (RIGHT)*	$420
#1L	*Rx7 FC Knuckle (LEFT)*	$420
#2	*Ackermann Plates*	$5
#3	*1/4 - 20 x 3/4 Bolt x1*	$0.30
#4	*1/4 - 20 Nylock nut*	$0.30

Rx7 FC Tension Arm Assembly Spare Parts

$204.39

Parts list

Prices in CAD currency

#1	*RX7 FC Tension Arm x1*	$179.99
#2	*3/7 - 16 Jam nut x1*	$1
#3	*RX7 FC Tension Arm Mount x1*	$50
#4	*M14 - 1.25 x 60mm x1*	$2
#5	*3/4 - 16 Chromoly Heim joint x1*	$24.99
#6	*Tension Arm Spacers x1set*	$6.50
#7	*M14 - 1.25 Nylock nut x1*	$1

Rx7 FC LCA to TA Assembly Spare Parts

$204.39

Parts list

Prices in CAD currency

#1	*Rx7 FD Tension arm x1*	$179.99
#2R	*Rx7 Lower Control arm x1 (RIGHT)*	$205
#2L	*Rx7 Lower Control arm x1 (LEFT)*	$205
#3	*1/2 - 20 x 2 Yellow zinc bolt x1*	$1.60
#4	*1/2 Yellow zinc washer x1*	$0.50
#5	*1/2 - 20 Nylock nut x1*	$1.10

Rx7 Mantis Assembly Spare Parts

$476.94

Parts list

Prices in CAD currency

#1R	Rx7 FC Knuckle x1 (RIGHT)	$420
#1L	Rx7 FC Knuckle x1 (LEFT)	$420
#2	Tie rod assembly x1	$160
#3	Tension Arm assembly x1	$254.99
#4	1/2 - 20 x 3 Yellow zinc bolt x1	$1.70
#5	1/2 Yellow zinc washer x1	$0.50
#6	1/2 - 20 Yellow zinc Nylock nut x1	$0.50
#7	1/2 - 20 x 3 1/2 Yellow zinc bolt x1	$1.60

Rx7 FC Tie Rod Assembly Spare Parts

$51.10

Parts list

Prices in CAD currency

#1	*9.5 inch Tie rod x1*	$45
#2	*Shackle Spacers 1xset*	$5
#3	*M14 - 1.5 Rack Bolt 1x*	$16.99
#4	*RX7 FC Tie rod Shackle 1x*	$44.99
#5	*5/8 - 18 Chromoly Heim joint 1x*	$21.99
#6	*5/8 - 18 Jam nut 1x*	$0.60
#7	*5/8 Spacers 1xset*	$5

Rx7 Lower Control Arm Assembly Spare Parts

$232.79

Parts list

Prices in CAD currency

#1R	*RX7 FC Lower Control arm (RIGHT)*	$205
#1L	*RX7 FC Lower Control arm (LEFT)*	$205
#2	*3/4 - 16 Jam Nut*	$1
#3	*Lower Control arm Spacers x1set*	$10
#4-6	*Bump Stop*	$1.60
#5	*3/4 - 16 Chromoly Heim*	$24.99
